KU 425N

UL Listed KU Series 16-80A

  • Rotary switch with extended handle
  • UL 60947-4-1A
  • CCA, CB certificates
  • ISO 9001
  • Compact size
  • DIN-rail mounting
  • Switch technology by means of silver contacts ensures safe and durable operation
  • Compatible with handles LK10UL and LK11UL
  • Shafts L=100/200/300 AD11 and L=100/200/300 AD11/VT

Product details

SKU KU 425N
Ampere Rating (600V) 25 A
EAN 6419410215203
HP 208V 5HP
HP 480V 15HP
HP 600V 10HP
Number of Poles 4
Operation Rotary
Weight (lb/kg) 0.485 / 0.22
Wire Size (Cu Only) 14-8 AWG

Dimensional drawing

Product diagram
