KE 325 A A2S 2XM25M KST16M

Isolating switch 3x25A IP66

KE 325 A A2S 2XM25M KST16M

Katko IsoSafe side-operated aluminium isolators are robust solutions for demanding industrial environments where mechanical strength and reliable isolation are essential. The aluminium enclosure provides high impact resistance, good corrosion protection and wide operating temperature capability, making it suitable for both indoor and outdoor use.

Fully rated load break performance, padlockable handle positions and flexible cable entry options support safe and efficient operation. Designed to meet international standards, IsoSafe aluminium isolators deliver long service life and dependable performance in heavy-duty applications.

Numer produktu
30449
E-number FI
3600315
Rated operational current AC-23A 415V (A)
25
Enclosure type
Aluminium
Enclosure
A2S (102.5 x 157 x 79.5)
Download Product Datasheet

Looking for more information about this product?

Our team is here to help.

 Pokaż kompletne dane

Product details and documents

Technical data

Cable entries
2 x M25 (11,0-17,0 mm), metal; 1 x plug, metal
delivery_time
10
Depth
79.5 mm
EMC
false
Enclosure
A2S (102.5 x 157 x 79.5)
Enclosure type
Aluminium
ETIM Class
EC000216
E-number FI
3600315
GTIN
6419410304495
Height
157 mm
IP rating
IP66
Max. term. torque (Nm)
1.8
Mech. endurance (no. of oper.)
20000
Net weight
1.699 kg
Nom. values w/cable size (mm²)
4
Number of poles
3
Product type
KE 325 A A2S 2XM25M KST16M
Rated breaking cap. ICN AC-23A 415V (A)
200
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
8
Rated insulation volt. Ui (V)
800
Rated operational current AC-21A 415V (A)
25
Rated operational current AC-21A 500V (A)
25
Rated operational current AC-21A 690V (A)
25
Rated operational current AC-22A 415V (A)
25
Rated operational current AC-22A 500V (A)
25
Rated operational current AC-22A 690V (A)
25
Rated operational current AC-23A 415V (A)
25
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
11
Rated short-ckt. making cap. Icm 415V (kA)
1.6
Rated short-time withstand current 1s Icw 415V (kA)
1.1
Rated therm. current Ithe (A)
25
Rated therm. current Ith (A)
25
Short product description
Isolating switch 3x25A IP66
Switch type
Load Break Switch
Technical name
3x25A 400V 11kW
Terminals bolt size (Cu mm²)
1,5..16
Volume
1.2794 l
Width
102.5 mm

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 depth
55.6 mm
Package size 1 GTIN code
6419410304495
Package size 1 height
128 mm
Package size 1 volume
0.5907 l
Package size 1 weight
1.699 kg
Package size 1 width
83 mm
Sales unit
1
