Manual motor controller 3x60A

KER 360UL98 R4B

Manual motor controller 3x60A

Katko UL98 listed enclosed disconnects (60-400A) are engineered for applications requiring the highest level of disconnect performance under UL standards. They are designed for high-performance switching and long-term reliability.

Used in industrial and commercial power systems, these disconnects ensure safe operation where strict compliance and durability are essential.

GTIN
6419410315682
Ampere rating 600V
60
Enclosure type
Stainless steel (AISI 304)
Enclosure
R4B (200 x 300 x 150 mm)
Pokaż kompletne dane

Product details and documents

Technical data

Ampere rating 600V
60.0
Depth
120 mm
EMC
false
Enclosure
R4B (200 x 300 x 150 mm)
Enclosure type
Stainless steel (AISI 304)
ETIM Class
EC000216
GTIN
6419410315682
Height
300 mm
HP 208V
1.5
HP 240V
20.0
HP 480V
40.0
HP 600V
60.0
Long product name
UL98-listed, 3-pole, Stainless steel enclosure (AISI 304); W200 x H300 x D120
Number of poles
3
Product type
KER 360UL98 R4B
Short product description
Manual motor controller 3x60A
Technical name
3x40A 400V 22kW
UL
UL98
Volume
7.2 l
Width
200 mm
Wire size Cu
8-1/0 AWG

No dimensional drawings available for this product.

Dimensional drawing

No dimensional drawings available for this product.

Logistical data

Package size 1 depth
300 mm
Package size 1 GTIN code
6419410363492
Package size 1 height
1200 mm
Package size 1 volume
216 l
Package size 1 width
600 mm

Downloadables

    No downloadable files available for this product.
