KKVM 332CCUL YR M3
KKVM 332CCUL YR M3
Katko FuseSafe enclosed fuse switches combine reliable switching and fuse protection in a compact, enclosed solution for professional electrical installations. Available with polycarbonate, sheet steel and stainless steel enclosures, the range offers suitable options for a wide variety of industrial, commercial and infrastructure applications.
The enclosed design provides added protection for fuse circuits and electrical connections, supporting safe operation and clear isolation. With durable construction and multiple enclosure material options, Katko enclosed fuse switches deliver dependable performance in environments ranging from standard indoor installations to demanding industrial conditions.
Rated operational current AC-22A 415V (A)
Rated operational current AC-22A 690V (A)
Enclosure
Enclosure type
Technical data
Ampere rating 600V
32.0
delivery_time
10
Depth
96 mm
Enclosure
M3 (144 x 190 x 96 mm)
Enclosure type
Polycarbonate
ETIM Class
EC001040
GTIN
6419410377673
Height
190 mm
HP 208V
7.5
HP 240V
0.0
HP 415V
7.5
HP 480V
20.0
HP 600V
15.0
Net weight
1.1966 kg
Nom. values w/cable size (mm²)
6
Number of poles
3
Product type
KKVM 332CCUL YR M3
Rated breaking cap. ICN AC-23A 415V (A)
256
Rated fused short-ckt current back-up fuse opt 1 (A)
40
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated insulation volt. Ui (V)
600
Rated operational current AC-21A 415V (A)
32
Rated operational current AC-21A 500V (A)
32
Rated operational current AC-21A 690V (A)
32
Rated operational current AC-22A 415V (A)
32
Rated operational current AC-22A 500V (A)
32
Rated operational current AC-22A 690V (A)
32
Rated operational current AC-23A 415V (A)
32
Rated operational current AC-23A 500V (A)
32
Rated operational current AC-23A 690V (A)
32
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
15
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
22
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
30
Rated therm. current Ithe (A)
30
Rated therm. current Ith (A)
30
Switch type
Switch Fuse
UL
UL 60947-4-1A
Volume
2.6266 l
Width
144 mm
Wire size Cu
14-8 AWG
Dimensional drawing
Logistical data
Package size 1
1
Package size 1 depth
96 mm
Package size 1 GTIN code
6419410377673
Package size 1 height
190 mm
Package size 1 volume
2.6266 l
Package size 1 weight
1.1966 kg
Package size 1 width
144 mm
Sales unit
1
Downloadables
- Dimensional drawings media (IsoSafe_M3_Dim.png)
- Brochures (Katko IsoSafe Catalogue - Safety Switches & Isolators)
- Brochures (Katko IsoSafe Tuoteluettelo - Turvakytkimet FI)
- Brochures (Katalog Wyrobów KATKO IsoSafe – Wyłączniki bezpieczeństwa i rozłączniki PL)
- Brochures (Katko IsoSafe UL Listed Selection Brochure EN)
- DWG files (IsoSafe_M3_LK10.zip)
- Installation manuals (KATKO_IsoSafe_M3_installation_manual_36.pdf)
