Enclosed switch fuse 3x32A DIN 10x38

KKVM 332UL YR M3

Enclosed switch fuse 3x32A DIN 10x38

Katko FuseSafe enclosed fuse switches combine reliable switching and fuse protection in a compact, enclosed solution for professional electrical installations. Available with polycarbonate, sheet steel and stainless steel enclosures, the range offers suitable options for a wide variety of industrial, commercial and infrastructure applications.

The enclosed design provides added protection for fuse circuits and electrical connections, supporting safe operation and clear isolation. With durable construction and multiple enclosure material options, Katko enclosed fuse switches deliver dependable performance in environments ranging from standard indoor installations to demanding industrial conditions.

Rated operational current AC-22A 415V (A)
32
Rated operational current AC-22A 690V (A)
32
Enclosure
M3 (144 x 190 x 96 mm)
Enclosure type
Polycarbonate
Pokaż kompletne dane

Product details and documents

Technical data

Ampere rating 600V
32.0
Depth
96 mm
Enclosure
M3 (144 x 190 x 96 mm)
Enclosure type
Polycarbonate
ETIM Class
EC001040
GTIN
6419410377666
Height
190 mm
HP 208V
7.5
HP 240V
0.0
HP 415V
7.5
HP 480V
20.0
HP 600V
15.0
Max. term. torque (Nm)
1.8
Mech. endurance (no. of oper.)
50000
Net weight
1.1838 kg
Nom. values w/cable size (mm²)
6
Number of poles
3
Product type
KKVM 332UL YR M3
Rated breaking cap. ICN AC-23A 415V (A)
256
Rated breaking cap. ICN AC-23A 500V (A)
256
Rated breaking cap. ICN AC-23A 690V (A)
256
Rated fused short-ckt current back-up fuse opt 1 (A)
40
Rated fused short-ckt current peak value (kA)
6
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
8
Rated insulation volt. Ui (V)
800
Rated operational current AC-21A 415V (A)
32
Rated operational current AC-21A 500V (A)
32
Rated operational current AC-21A 690V (A)
32
Rated operational current AC-22A 415V (A)
32
Rated operational current AC-22A 500V (A)
32
Rated operational current AC-22A 690V (A)
32
Rated operational current AC-23A 415V (A)
32
Rated operational current AC-23A 500V (A)
32
Rated operational current AC-23A 690V (A)
32
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
15
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
22
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
30
Rated short-ckt. making cap. Icm 690V (kA)
2.5
Rated short-time withstand current 1s Icw 690V (kA)
1.7
Rated therm. current Ithe (A)
32
Rated therm. current Ith (A)
32
Short product description
Enclosed switch fuse 3x32A DIN 10x38
Switch type
Switch Fuse
Technical name
3x32 400V 15kW
Terminals bolt size (Cu mm²)
1,5..16
UL
UL 60947-4-1A
Volume
2.6266 l
Width
144 mm
Wire size Cu
14-8 AWG

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 depth
96 mm
Package size 1 GTIN code
6419410377666
Package size 1 height
190 mm
Package size 1 volume
2.6266 l
Package size 1 weight
1.1838 kg
Package size 1 width
144 mm
Sales unit
1
