KKVR 332CCUL YR RA4

KKVR 332CCUL YR RA4

Katko FuseSafe enclosed fuse switches combine reliable switching and fuse protection in a compact, enclosed solution for professional electrical installations. Available with polycarbonate, sheet steel and stainless steel enclosures, the range offers suitable options for a wide variety of industrial, commercial and infrastructure applications.

The enclosed design provides added protection for fuse circuits and electrical connections, supporting safe operation and clear isolation. With durable construction and multiple enclosure material options, Katko enclosed fuse switches deliver dependable performance in environments ranging from standard indoor installations to demanding industrial conditions.

Rated operational current AC-22A 415V (A)
32
Rated operational current AC-22A 690V (A)
32
Enclosure
RA4 (160 x 260 x 90 mm)
Download Product Datasheet

Looking for more information about this product?

Our team is here to help.

 Pokaż kompletne dane

Product details and documents

Technical data

GTIN
6419410377710
Ampere rating 600V
32.0
Depth
90 mm
Enclosure
RA4 (160 x 260 x 90 mm)
ETIM Class
EC001040
Height
260 mm
HP 208V
7.5
HP 240V
0.0
HP 415V
7.5
HP 480V
20.0
HP 600V
15.0
Net weight
2.5897 kg
Nom. values w/cable size (mm²)
6
Number of poles
3
Product type
KKVR 332CCUL YR RA4
Rated breaking cap. ICN AC-23A 415V (A)
256
Rated fused short-ckt current back-up fuse opt 1 (A)
40
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated insulation volt. Ui (V)
600
Rated operational current AC-21A 415V (A)
32
Rated operational current AC-21A 500V (A)
32
Rated operational current AC-21A 690V (A)
32
Rated operational current AC-22A 415V (A)
32
Rated operational current AC-22A 500V (A)
32
Rated operational current AC-22A 690V (A)
32
Rated operational current AC-23A 415V (A)
32
Rated operational current AC-23A 500V (A)
32
Rated operational current AC-23A 690V (A)
32
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
15
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
22
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
30
Rated therm. current Ithe (A)
30
Rated therm. current Ith (A)
30
Switch type
Switch Fuse
UL
UL 60947-4-1A
Volume
3.744 l
Width
160 mm
Wire size Cu
14-8 AWG

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 depth
90 mm
Package size 1 GTIN code
6419410377710
Package size 1 height
260 mm
Package size 1 volume
3.744 l
Package size 1 weight
2.5897 kg
Package size 1 width
160 mm
Sales unit
1
