KVKEM 3125 M5 2XM50P

KVKEM 3125 M5 2XM50P

Katko FuseSafe enclosed fuse switches combine reliable switching and fuse protection in a compact, enclosed solution for professional electrical installations. Available with polycarbonate, sheet steel and stainless steel enclosures, the range offers suitable options for a wide variety of industrial, commercial and infrastructure applications.

The enclosed design provides added protection for fuse circuits and electrical connections, supporting safe operation and clear isolation. With durable construction and multiple enclosure material options, Katko enclosed fuse switches deliver dependable performance in environments ranging from standard indoor installations to demanding industrial conditions.

Rated operational current AC-22A 415V (A)
125
Rated operational current AC-22A 690V (A)
125
Enclosure
M5 (271 x 380 x 152 mm)
Enclosure type
Polycarbonate
IP rating
IP66

Looking for more information about this product?

Our team is here to help.

 Pokaż kompletne dane

Product details and documents

Technical data

Depth
152 mm
Enclosure
M5 (271 x 380 x 152 mm)
Enclosure type
Polycarbonate
ETIM Class
EC000216
Fuse type DIN
000/00
GTIN
6419410380246
Height
380 mm
IP rating
IP66
Max. term. torque (Nm)
6
Mech. endurance (no. of oper.)
20000
Net weight
4.7753 kg
Nom. values w/cable size (mm²)
50
Number of poles
3
Product type
KVKEM 3125 M5 2XM50P
Rated breaking cap. ICN AC-23A 415V (A)
1000
Rated breaking cap. ICN AC-23A 500V (A)
1000
Rated breaking cap. ICN AC-23A 690V (A)
1000
Rated fused short-ckt current back-up fuse opt 1 (A)
125
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
8
Rated insulation volt. Ui (V)
690
Rated operational current AC-21A 415V (A)
125
Rated operational current AC-21A 500V (A)
125
Rated operational current AC-21A 690V (A)
125
Rated operational current AC-22A 415V (A)
125
Rated operational current AC-22A 500V (A)
125
Rated operational current AC-22A 690V (A)
125
Rated operational current AC-23A 415V (A)
125
Rated operational current AC-23A 500V (A)
125
Rated operational current AC-23A 690V (A)
125
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
55
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
75
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
110
Rated short-ckt. making cap. Icm 690V (kA)
6
Rated short-time withstand current 1s Icw 690V (kA)
4
Rated therm. current Ithe (A)
125
Rated therm. current Ith (A)
125
Switch type
Switch Fuse
Terminals bolt size (Cu mm²)
6..70
Volume
15.653 l
Width
271 mm

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 GTIN code
6419410380246
Sales unit
1
