Katko ConnectSafe cable connectors are compact and reliable connectors designed for secure cable termination. Supporting a wide range of conductor sizes, they enable fast installation, excellent electrical contact and space-efficient designs. These connectors are ideal for professional electrical installations where reliability and clarity are essential.
Looking for more information about this product?
Our team is here to help.
Product details and documents
Technical data
Al (mm²)
35-240
Cu (mm²)
35-240
Depth
47 mm
ETIM Class
EC000897
E-number FI
1942131
GTIN
6419410378755
Height
65 mm
In Al
630.0
In Cu
850.0
Key size
Hex 8
Net weight
0.4861 kg
Product type
KKL2X240LR
Short product description
Cable connector KKL 2xAl/Cu 35-240mm2
Torque Al/Cu (Nm)
25 (35-120 mm²) / 55 (150-240 mm²)
Volume
0.1864 l
Width
61 mm
No dimensional drawings available for this product.
Dimensional drawing
No dimensional drawings available for this product.
Logistical data
Package size 1
16
Package size 1 GTIN code
6419410378755
Package size 1 weight
0.4861 kg
Downloadables
No downloadable files available for this product.
