Katko ConnectSafe terminal blocks provide safe and reliable electrical connections for demanding industrial and building applications. Suitable for both copper and aluminum conductors, they are available with screw and DIN-rail mounting options, enabling fast and easy installation. Their robust construction and clear design ensure long service life and trouble-free operation. ConnectSafe terminals meet high industry standards and international approvals, delivering dependable performance for professional use.
Technical data
Al (mm²)
1,5-16
Cu (mm²)
1,5-16
delivery_time
10
Depth
31.5 mm
ETIM Class
EC000897
E-number FI
1942120
GTIN
6419410484364
Height
46.7 mm
In Al
75.0
In Cu
76.0
Key size
Hex 4
Net weight
0.02 kg
Nominal voltage
1000V AC
Product type
KL1X16
Short product description
Terminal block KL 1xAl/Cu 1,5-16mm2 Grey
Torque Al/Cu (Nm)
5
Volume
0.0197 l
Width
13.4 mm
Dimensional drawing
Logistical data
Package size 1
60
Package size 1 GTIN code
6419410484364
Package size 1 weight
0.02 kg
Downloadables
- Dimensional drawings media (ConnectSafe_KL1X16_Dim.png)
- Brochures (Katko ConnectSafe Catalogue - Terminal Blocks and Cable Connectors EN)
- Brochures (Katko ConnectSafe Tuoteluettelo - Liittimet ja Kojeliittimet FI)
- STEP files (ConnectSafe_KL1X16__2.zip)
- DWG files (ConnectSafe_KL1x16.zip)
- Installation manuals (KATKO_ConnectSafe_KL_range_installation_manual_79_en.pdf)
- Installation manuals (KATKO_ConnectSafe_KL_range_installation_manual_79_fi.pdf)
- Installation manuals (KATKO_ConnectSafe_KL1X16_KL5X1X16_installation_manual_88_en.pdf)
