Enclosed switch fuse 3x250A DIN 1

KVKET 3250 T6

Enclosed switch fuse 3x250A DIN 1

Katko FuseSafe enclosed switch fuses combine reliable switching and fuse protection in a safe and space-saving solution for professional electrical installations. Available in polycarbonate, steel, and stainless steel enclosures, FuseSafe is suitable for a wide range of industrial, building, and infrastructure applications. Durable enclosure materials ensure reliable performance in both standard indoor installations and demanding industrial environments.

Rated operational current AC-22A 415V (A)
250
Rated operational current AC-22A 690V (A)
250
Enclosure
T6 (400 x 600 x 200 mm)
Enclosure type
Painted sheet steel
View full details

Product details and documents

Technical data

Depth
200 mm
Enclosure
T6 (400 x 600 x 200 mm)
Enclosure type
Painted sheet steel
ETIM Class
EC001040
Fuse type BS88
B1-B3
Fuse type DIN
1
Fuse type fixing centres (mm)
111
Fuse type screw size
M10
Fuse type torque (Nm)
15
GTIN
6419410393307
Height
600 mm
Max. term. torque (Nm)
30..40
Mech. endurance (no. of oper.)
16000
Net weight
16.6587 kg
Nom. values w/cable size (mm²)
120
Number of poles
3
Product type
KVKET 3250 T6
Rated breaking cap. ICN AC-23A 415V (A)
2000
Rated breaking cap. ICN AC-23A 500V (A)
2000
Rated breaking cap. ICN AC-23A 690V (A)
2000
Rated fused short-ckt current back-up fuse opt 1 (A)
250
Rated fused short-ckt current peak value (kA)
18
Rated fused short-ckt current RMS Ik opt 1 (kA)
80
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
12
Rated insulation volt. Ui (V)
1000
Rated operational current AC-21A 415V (A)
250
Rated operational current AC-21A 500V (A)
250
Rated operational current AC-21A 690V (A)
250
Rated operational current AC-22A 415V (A)
250
Rated operational current AC-22A 500V (A)
250
Rated operational current AC-22A 690V (A)
250
Rated operational current AC-23A 240V (A)
250
Rated operational current AC-23A 415V (A)
250
Rated operational current AC-23A 500V (A)
250
Rated operational current AC-23A 690V (A)
250
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
132
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
160
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
250
Rated short-ckt. making cap. Icm 690V (kA)
7
Rated short-time withstand current 1s Icw 690V (kA)
5
Rated therm. current Ithe (A)
250
Rated therm. current Ith (A)
250
Short product description
Enclosed switch fuse 3x250A DIN 1
Switch type
Switch Fuse
Technical name
3x250 400V 132kW
Terminals bolt size (Cu mm²)
M10
Volume
48 l
Width
400 mm

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 depth
200 mm
Package size 1 GTIN code
6419410393307
Package size 1 height
600 mm
Package size 1 volume
48 l
Package size 1 weight
16.6587 kg
Package size 1 width
400 mm
Sales unit
1
